Description
Frame: 6” X 10.5# Channel Main w/ 3” Channel Cross Members on 16.75” CL, 3/8” X 5” HRFB Belting 18” Forward and Aft of Front Bulkhead
Deck: 8/4 (2”) X 12” Apitong Hardwood
Hitch: 2-Bolt, 14K Rated Pintle Ring on an 8” Adjustable Channel Mounted Flush to Bottom of 6” Channel Frame
Axles: 2 ea. 6,000 Lbs. w/ 8 on 6.5” 1/2” Lugs Electric Brakes and Grease Lube on All 4-Hubs (89HF/76”SC)
Suspension: 3,500 Lbs. Slipper Springs w/ 33” Axle Split using HGR-202 & A/P-202 Kits
Tires: 5 ea. ST235/80R16 “E” 10-Ply on a 8-Hole HD Spoke Wheel- Spare Shipped Loose
Ramps: 2 ea. 18” W X 71.5” L, 3” Channel Tapered to a Point w/ 3” X 2” X 3/16” Angle X-Pieces on 8.75” Centers Capped w/ 6/4 (1.5”) X 7” Apitong Hardwood with Rubber Traction Mat w/ 1 ea. 1-1/4” Spring Assist per Ramp
Tie Downs: 3 ea. 5/8” D-rings Across Front Bulkhead, 5 ea. 5/8” D-rings per Side evenly Spaced
Lights: Vison Brand LED, Recessed, Sealed, Shock Proof & DOT Approved Electrical: Wire Pulled thru Metal Conduit, Heat Shrink Butt Connectors, Rubber Grommets where Wire Pass thru Metal. Wire Terminated in a Junction Box w/ 36″ L 6-Conductor Wire Harness
Plug Type: Pollack 11-700 on a 6-Conductor Wire Harness
Jack: 7,000 Lbs. Drop Foot Side Wind
Toolbox: 10” H Tapered Compartment in Tongue w/ 10 Ga Lockable Lid Sign & Tool Rack: 1 ea. Across Front w/ 6 ea. Tool Holders 1 ea. Along Left Hand Side @ Mid-Fender
Cone Holders: 2 ea. per Side (4 ea. Total), Top of Fenders
GVWR: 12,000 Lbs.
Empty Weight: 2,000 Lbs.
Maximum Capacity: 10,000 Lbs.
Color: White
